Humidity and temperature transmitter with 4-20mA outputs

Reference AR004146

  • Low cost transmitter.
  • Temperature and humidity.
  • Exterior and interior.
  • Integrated sensors.
788.64KB Download

Introduction Manual | Humidity and temperature transmitter with 4-20mA outputs

Product features Humidity and temperature transmitter with 4-20mA outputs

TECHNICAL DATA

Transmitter relative humidity and temperature ambient and low cost.

Use Case exterior and interior.

Temperature and relative humidity sensors integrated

INCLUDED IN DELIVERY

  • P3110E
  • Manual
  • Traceable calibration certificate


MEASURED VALUES

- Temperature
- Relative humidity

Relative humidity range: 0 to 100%

Accuracy of the relative humidity measurement: ± 3,0% relative humidity from 5 to 95% at 23 ° C

Accuracy of temperature output: ± 0.6 ° C

Temperature operating range: -30 to +80 ° C

Humidity sensor temperature compensation range: the entire temperature range

Current outputs - two-wire connection: 4-20mA, galvanically isolated

Filtering capacity of the sensor cover: 0.025mm - filter with stainless steel mesh

Housing protection with electronics: Electronics IP65, sensors IP40

Power : 9-30Vdc

Dimensions: 89 x 170 x 40 mm (W x H x D), rod length 75 mm

Weight: about 150g

Warranty: 3 years
