Match the reference to the application.
The application uses BME688 sensing and processing capabilities. Define which raw or processed outputs are required and how they will be interpreted.
Review the specification →GUILCOR · Digital sensing
Combined environmental sensing and gas-resistance measurement for application-specific air monitoring. Define the signal processing and validation behind every displayed indicator.

Understand the reference
A gas-resistance signal responds to the surrounding gas mixture. Air-quality indicators and CO₂-equivalent outputs require additional processing; they are not direct selective CO₂ concentration measurements.
SELECTION / YOUR APPLICATION
The application uses BME688 sensing and processing capabilities. Define which raw or processed outputs are required and how they will be interpreted.
Review the specification →Compare the humidity and temperature channels, host interface, electrical requirements and installation. The enclosure and exposure of the sensing opening are part of the selection.
Explore BME280 →Keep the exact device and host-driver references. Check commands, data conversion, connector and protective opening as well as the required measurement interval.
Prepare your enquiry →These links support a specification review. They do not establish interchangeable parts or availability of a complete assembly.
Interactive application guide
Distinguishes a measured channel from a processed estimate. No health or safety classification is inferred from a single example value.
Enable JavaScript to use this guide.
Technical reference
| IC temperature range | −40 to +85 °C |
|---|---|
| Channels | Temperature, humidity, pressure and gas resistance |
| Pressure / humidity | 300 to 1100 hPa / 0 to 100 %RH |
| Supply | VDD 1.71 to 3.6 V; VDDIO 1.2 to 3.6 V |
| Interfaces | I²C and SPI |
| Processing | Gas heater profiles, Bosch BSEC and application-trained classification where used |
The sensing IC, finished probe and host electronics have separate requirements. Cable insulation, sealing, connector, supply and mounting may impose a narrower operating range. A temperature step is not an accuracy guarantee, and an electronic conversion time is not a thermal response time.
For environmental trends or validated gas-pattern applications. Do not use an equivalent output as a direct gas concentration or a certified life-safety alarm.
Wiring and integration
Plan airflow, heater power and thermal separation. Use the manufacturer driver and the correct processing configuration for the intended measurement mode.
SDA and SCL usually need pullups to a compatible logic supply. Select them for bus capacitance, rise time and the devices that pull the lines low. Cable length, connectors and level shifters change the electrical behaviour.
Use 7-bit addresses consistently in the host API. Check clock stretching, timeout and recovery support. Successful communication does not prove that the reading is fresh or that the sensor is mounted at a representative measurement point.
Acquisition sequence
Confirm the part, address, supply and measurement mode.
Issue the device-specific command and satisfy its timing and power needs.
Read the correct registers, check CRC where provided and reject invalid or stale results.
Apply the correct decoder or compensation, units and application limits.
Measurement quality
Choose the error limit over the actual operating interval. Add installation and readout effects. Define any calibration and periodic verification required by the application; factory calibration does not establish a universal no-maintenance policy.
A sheath, potting material and mounting contact change how fast the sensing element follows the medium. Verify response in the intended flow and installation, rather than using conversion time as the finished-probe response.
Average dissipation depends on supply, conversion duty and surrounding electronics. Test the assembled probe at the intended reading rate. Do not assume a universal self-heating offset from the interface name.
Form factor library
Choose the shape and mounting for the measurement point. These are GUILCOR probe families and a design service; confirm the compatible element, dimensions, cable and complete assembly for the selected reference.
Frequently asked questions
No. It is a processed estimate based on the gas-sensing response and algorithm assumptions, not a selective CO₂ measurement.
Only when addresses, voltage levels, timing and host support are compatible. Fixed duplicate addresses may require a multiplexer or separate bus.
It is commonly used for communication within electronic assemblies. Longer cables require an electrical design and validation appropriate to the installation; there is no universal permitted length.
Send the reference and full ordering code, measured quantities, operating interval, error and response requirements, mounting drawing, cable and connector, host interface and quantity.
Technical sources
GUILCOR / YOUR ENQUIRY
Describe both the electrical interface and the air reaching the sensor. Include the enclosure, airflow and exposure conditions when requesting an assembled probe.
Send the component marking, equipment reference and any photographs or documents you have. These provide a starting point for identifying what must be confirmed.
The outline helps prepare your enquiry. Copying it does not send a request.
FOUR DETAILS THAT MOVE THE DISCUSSION FORWARD
Exact device or module, interface, host or driver, supply and logic levels, addressing or wiring and measurement commands.
Temperature and humidity intervals, required accuracy and update rate, airflow, condensation risk, contamination and any additional measured quantities.
Sensing opening or filter, enclosure and ventilation, mounting location, nearby heat sources, connector and cable arrangement.
Sample and production quantities, target delivery, calibration or documentation needs, and the checks required before approval.
