CO2 concentration and temperature transmitter with 0-10 V outputs, integrated sensors

Reference: AR004418

CO2 concentration and temperature transmitter with 0-10 V outputs, integrated sensors
  • CO2 sensor.
  • Two 0-10 V outputs.
  • Easy installation.
  • Long term stability.

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "CO2 concentration and temperature transmitter with 0-10 V outputs, integrated sensors"

TECHNICAL DATA

Carbon dioxide level and temperature sensor.

The CO2 concentration and temperature transmitter with two 0-10 V outputs is especially designed for use in demanding interiors in building energy management and HVAC systems.

It was designed for easy installation on KU68 wiring boxes standard for household switches and sockets.

He's possible to turn off a large LCD screen two-line.

La computerized design provides long-term stability and failure indication.

The transmitter is designed for use in a non-aggressive environment.

INCLUDED IN DELIVERY

  • AR004418
  • Manual
  • Traceable calibration certificate
  • Free Tsensor configuration software


MEASURED VALUES

- Temperature
- CO2

CO2 concentration measurement range: 0 to 2000 ppm

Accuracy of CO2 concentration measurement: ± (50 ppm + 2% of reading) at 25 ° C and 1013hPa

Accuracy of temperature output: ± 0.5 ° C

Temperature units: degrees Celsius, Fahrenheit

Temperature range : -10 to + 50 ° C

IP protection: IP20

Power : 15-30Vdc

Dimensions: 88 x 106 x 33 mm (W x H x D)

Material: ABS

Color: White

Weight: approximately 150g

Warranty: 3 years

General

  • Reference AR004418
  • Name CO2 concentration and temperature transmitter with 0-10 V outputs, integrated sensors

Features

  • Measured CO2
  • Product Type Head / terminal probes
  • Communication 0 ... 10V

Attachments

CO2 concentration and temperature transmitter with 0-10 V outputs, integrated sensors - User manual
AR004418
Download (1.37MB)
CO2 concentration and temperature transmitter with 0-10 V outputs, integrated sensors - Quick start
AR004418
Download (648.24KB)
