Thermocouple with connection head with fitting - ATEX explosion-proof


Delivery in 3 to 5 weeks
  • Design temperature range: -40 .. + 800 ° C
  • Technological process installations in all industries
  • Installation in hazardous areas:
    Gases, vapors, mists (G): Zone 0, 1, 2
    Dust (D): Zone 20, 21, 22
    Mining: M2

Product features Thermocouple with connection head with fitting - ATEX explosion-proof


  • Single and double TC
  • Interchangeable mineral insulated measuring insert
  • Process connection welded to the protective tube
  • Protective tube diameter: Ø10, Ø11, Ø12, Ø15 mm
  • Protective tube material: stainless steel 1.4541 (AISI321) or other
  • ATEX cable gland I M2, II GD, IP65 (cable diameter Ø5..10mm)
  • Output signal: TC or 4..20 mA (option)

Assembly instructions

Signed sensors ex.jpg II 1/2G IIC T6 ÷ T5 Ga/Gb  et ex.jpg II 1/2D Ex ta/tb IIIC TX Da/Db  have been designed for temperature measurement in all gas, liquid, mist and dust explosion zones. In zone 0 or 20 can only be a protection tube. The connection head can only be in zones 1 (21) or 2 (22). The boundary between the zones is the threaded connection.

The sensors signed ex.jpg II 2G IIC Tx Gb and ex.jpg II 2D Ex tb IIIC TX Db have been designed for temperature measurement in zones 1 (21) and 2 (22).


The thermocouple thermometers in this series are designed to be screwed directly into the process, primarily into vessels and pipelines. These thermometers are suitable for liquid and gaseous media under moderate mechanical load and under normal chemical conditions.


The sensor consists of an interchangeable measuring insert, an external protective tube (thermowell) with neck and an aluminum connection head where the mounting of a temperature transmitter with an output signal 4 -20 mA / HART® or Profibus®PA is possible.

The measuring insert is the replaceable part of the complete sensor which reduces the time and cost of maintaining the measuring device installed in the object. The spring-loaded attachment of the measuring insert provides perfect pressure at the bottom of the protection tube, reduces reaction time to temperature changes and increases measurement accuracy and reduces natural vibrations, thus avoiding mechanical and electrical faults .

Insertion length, process connection, thermowell design, connection head as well as type and number of sensors and accuracy can be individually selected for the respective application.

Temperature transmitter (option)

The transmitter is mounted inside the sensor connection head, directly on the measuring insert.

Type GW1 aluminum, M20x1,5 cable gland
Type GW2 aluminum, 2 x cable gland M20x1,5
Type GW3 aluminum, M20x1,5 cable gland, with window for local LED display (LPI-02)
Type GW4 aluminum, 2 x cable gland M20x1,5, with window for local LED display (LPI-02)
Type S1 stainless steel, M20x1,5 cable gland
Type S2 stainless steel, 2 x cable gland M20x1,5
