Jacketed resistance thermometer, mini connector, intrinsically safe

Reference: GXI-TRP-BTWR

Jacketed resistance thermometer, mini connector, intrinsically safe
  • Measuring range: -50 .. + 600 ° C
  • General design of machines and equipment
  • Temperature measurement of liquids, gases and solids
  • All branches of industry
  • Installation in hazardous areas:
    Gases, vapors, mists (G): Zone 0, 1, 2
    Dust (D): Zone 20, 21, 22
    Mining: M1

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "Sheathed resistance thermometer, mini connector, intrinsically safe"

Features

  • XI-TRP-BTW Series Mineral Insulated RTD Sensor with Miniature Size Plug
  • Made of sheathed cable internally insulated with magnesium oxide (MgO)
  • Small dimensions, outer diameter from Ø1,5 mm
  • Short response time for temperature change
  • The sensor is foldable
  • Housing made of acid-resistant steel AISI316 (1.4401), AISI321 (1.4541)
  • Resistant to vibrations


Multiplicity

Possible combinations of duct diameters, multiplicity of sensor and connection lines:

Sheath diameter Simple, for example 1xPt100 Double, for example 2xPt100
2 fils 3 fils 4 fils 2 fils 3 fils 4 fils
Ø1,5 mm
Ø2,0 mm
Ø3,0 mm



Description

Sheathed resistance thermometers are made of metal sheathed cables whose inner wires (Cu or Ni) are insulated from each other and from the outer sheath with magnesium oxide (MgO) powder. This gives the sensor high vibration resistance, flexibility as well as temperature resistance and good electrical insulation.

These sensors are designed to directly measure the temperature in hard-to-reach places, as well as in all places where it is necessary to use flexible sensors of small diameters, high resistance to vibration and shock, and with a long time short response to temperature changes.

Due to the tight pressing of the insulating layer (MgO) and the proper structure of the inner wires and jacket, the sensors can be bent with a minimum bend radius of three times the outer diameter of the jacket.

General

  • Reference GXI-TRP-BTWR
  • Name Jacketed resistance thermometer, mini connector, intrinsically safe

Features

  • Product Type 2x Pt100
    2x Pt500
    2x Pt1000
    Pt100
    Pt500
    Pt1000
  • Number of threads 2
    3
  • Maximum operating temperature 600°C
  • Precision Class A + -0.15 ° C
    Class B + -0.3 ° C
  • Diameter 1.5 mm
    2 mm
    3 mm
  • Model With connector
    Jacketed probe
  • certification ATEX EXI
  • Cable length Without cable
