16-channel flush-mounted data logger.

Reference: AR004938

16-channel flush-mounted data logger.
  • Solution for monitoring.
  • Rack mounting.
  • Measures electrical signals.
  • Traceable calibration certificate.

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "16 Channel Flush Mount Data Logger."

TECHNICAL DATA

The complete solution for surveillance temperature, humidity and other values.

For use on the desk with rubber feet - see optional accessories.

For rack mount 19 - a 1U rack unit.

Data loggers are designed to measure, record, evaluate and further process signals electrical inputs, which are subject to relatively slow changes (> 1s).

In conjunction with the appropriate sensors and transducers, they suitable for monitoring physical quantities.

The device includes a traceable calibration certificate with declared metrological traceability of standards based on the requirements of EN ISO / IEC 17025.

The calibration sheet is always loaded as modules.

If the input requirements defined by the calibration certificate prove the calibration inputs according to the required configuration - more than one track for each of the 16 inputs.

INCLUDED IN DELIVERY

  • MS6R
  • Manual
  • Traceable calibration certificate
  • USB cable


MEASURED VALUES

- Temperature
- Relative humidity
- current
- voltage
- Two state signal
- Frequency
- Resistance
- Event log

Total memory capacity: 2 MB (up to 480 values)

Type of memory: Internal SRAM, backed up by lithium battery

Recording modes: non-cyclic data - logging stops after filling the cyclic memory - after filling the memory, the oldest data is overwritten with new ones

Data logging interval: individually adjustable for all input channels from 1 second to 24 hours

Real time clock: year, leap year, month, day, hour, minute, second, backed up by lithium battery

AD converter resolution (analog channels): 16 bits, conversion time approx.60 ms / channel

Communication speed: 9600, 19200, 57600, 115200 Bd, 230400 * Bd (* applicable for USB, Ethernet)

Power : 24Vdc, consumption of the data logger itself approx.80 mA

Operating temperature range: 0 to +50 ° C

Dimensions including connectors: 483 x 230 x 44 mm (W x D x H) - one 1U rack unit

Dimensions (without rack holder): 225 x 230 x 44 mm (W x D x H) - one 1U rack unit

Protection: IP20

Weight: approx. 800 g

Warranty: 3 years

General

  • Reference AR004938
  • Name 16-channel flush-mounted data logger.

Features

  • Measured Humidity
  • Type Fixed
  • Product Type Data loggers
  • Communication ETHERNET - TCP / IP

Attachments

16-channel flush-mounted data logger. - Introduction Manual
AR004795, AR004938
Download (5.12MB)
16-channel flush-mounted data logger. - Configurable
AR004795
Download (660.17KB)
