Indoor temperature sensor

SD room temperature sensor - CAN protocol

GSD104R
In production :  3 to 5 weeks
All of this indoor temperature sensors with digital CAN / CANopen output - SD 104  are designed for measuring the temperature of gaseous substances in areas protected from water - for example for measuring the temperature in premises (schools, theaters, conference rooms, etc.), offices, interiors of houses of home or halls. Its aesthetic design and high-quality materials guarantee installation in any type of environment, even in interiors with high aesthetic requirements.
Quantity

International shipping

FREE shipping in EU from 70 € HT purchase

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment term.

+33-233-611-670

English - French - German - Spanish

Room sensor

Indoor temperature sensors with digital output CAN / CANopen - SD 104 consist of a plastic head with grooves in which is placed a printed circuit board with individual sensors or a converter in order to guarantee a specific digital output according to the type of sensor.

The temperature range of the sensors is defined in the table of technical parameters for each variant. The sensors comply with protection class IP 30 in accordance with the modified standard EN 60529. The recommended location is at a height of 1,5 m on the interior wall, in the area of ​​movement of people, away from sunny places and places affected by the temperature of walls, radiators or light.

The sensors are designed to operate in a chemically non-aggressive environment, the method of use must be chosen according to the temperature and the chemical resistance of the sensor head.

Sensor type SD 104
Output signal  CAN / CANOPen-CIA DS 301
Measuring range                  -30 to 70 ° C
Measurement accuracy ± 0,5 ° C
Supply voltage 15 to 30 V DC
Nominal supply voltage Un 24 V DC
Consumption / supply current maximum: 500 mW, typical: 300 mW
Degree of protection IP 30 according to EN 60529, as modified
Working conditions

ambient temperature: -30 to 70 ° C
relative humidity:
atmospheric pressure maximum of 85% : 87 to 107 kPa

Head dimensions 71,9 x 59 x 27 mm
Head material LEXAN
Recommended conductor cross-section 0,14 to 1 mm 2
Weight min 50 g

Product installation
SD 104 probe connection diagram

Information

Measured
Temperature
Communication
CAN
