Ethernet temperature probe

Reference: AR003825

Ethernet temperature probe
  • P-line web sensor
  • Integrated temperature sensor.
  • Remote alarm.
  • TCP / IP communication

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "Ethernet Temperature Sensor"

TECHNICAL DATA

P-line web sensor with integrated temperature sensor.

Alarm remote.

Processing and analysis of measured data

  • Online in Cloud
  • Database software
  • Integration into third-party systems


INCLUDED IN DELIVERY

  • P8510
  • Manual
  • Traceable calibration certificate
  • Free Tsensor configuration software
  • Cloud for 3 months


MEASURED VALUES

- Temperature

Accuracy of temperature measurement: ± 0,8 ° C at -10 ° C, ± 2 ° C below -10 ° C

Resolution: 0.1 ° C

Measuring interval: 2s

Supported units: degrees Celsius, degrees Fahrenheit

Temperature operating range: -30 to +80 ° C

Protection: IP30

LAN connection: RJ-45, 10Base-T or 100Base-TX connector

Communication protocols: WWW, ModbusTCP, SNMPv1, SOAP, XML

Alarm protocols: Email, SNMP Trap, Syslog

Configuration: T-Sensor, WWW configuration

Power: 5 VDC, max. power consumption 1W

Power cable : coaxial, diameter 5,5 x 2,1 mm

Dimensions: 88,5 x 126 x 39,5 mm (W x H x D), rod length 53 mm

Weight: approx. 130g

Warranty: 3 years

General

  • Reference AR003825
  • Name Ethernet temperature probe

Features

  • Measured Temperature
  • Product Type Ethernet
  • Protection sign IP30
  • Maximum operating temperature 80°C
  • Model Exterior
    Terminal block probe
  • Cable length With terminal block

Attachments

Ethernet Temperature Probe - Cloud Security
AR003826 / AR005075 / AR003825 / AR004617 / AR005351 / AR006586 / AR003828
Download (1.52MB)
Ethernet Temperature Probe - Cloud Support
AR003826 / AR005075 / AR003825 / AR004617 / AR005351 / AR006586 / AR003828
Download (1.2MB)
Ethernet Temperature Probe - Introduction Manual
AR003825 / AR004617 / AR005351
Download (3.62MB)
Ethernet Temperature Probe - Quick Start
AR003825 / AR004617 / AR005351
Download (573.93KB)
