Ethernet POE temperature probe

Reference: AR003826

Ethernet POE temperature probe
  • Web Sensor P-line
  • Integrated temperature sensor.
  • Remote alarm.
  • Easy wireless communication.
Delivery in 3 to 5 weeks

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "Ethernet POE temperature sensor"

TECHNICAL DATA

Web Sensor with integrated temperature sensor and PoE power

Processing and analysis of measured data

  • Online in Cloud
  • Database software
  • Integration into third-party systems


INCLUDED IN DELIVERY

  • P8610
  • Manual
  • Traceable calibration certificate
  • Free Tsensor configuration software
  • Cloud for 3 months


MEASURED VALUES

- Temperature

Temperature measurement uncertainty: ± 0.8 ° C above -10 ° C, ± 2 ° C below -10 ° C

Resolution: 0.1 ° C

Measuring interval: 2 s

available units: degrees Celsius, Fahrenheit

Temperature measuring range: -20 to +60 ° C

Protection sign : IP30

LAN connection: RJ-45, 10Base-T or 100Base-TX connector

Communication protocols: WWW, ModbusTCP, SNMPv1, SOAP, XML

Alarm Protocols: Email, SNMP Trap, Syslog

Configuration: T-Sensor, WWW configuration

Supply : Power over Ethernet according to IEEE 802.3af or 5Vdc

connector type: co-axial, diameter 5.5 x 2.1 mm

Dimensions: 88.5 x 126 x 39.5 mm (W x H x D), probe length 53 mm

Weight: approx. 145g

Warranty: 3 years

General

  • Reference AR003826
  • Name Ethernet POE temperature probe

Features

  • Measured Temperature
  • Product Type Ethernet
  • Protection sign IP30
  • Maximum operating temperature 60°C
  • Model Exterior
    Terminal block probe
  • Cable length With terminal block

Attachments

POE Ethernet Temperature Sensor - Introduction Manual
AR003826 / AR005075 / AR003827
Download (2.63MB)
POE Ethernet Temperature Probe - Cloud Security
AR003826 / AR005075 / AR003825 / AR004617 / AR005351 / AR006586 / AR003828
Download (1.52MB)
POE Ethernet Temperature Sensor - Cloud Support
AR003826 / AR005075 / AR003825 / AR004617 / AR005351 / AR006586 / AR003828
Download (1.2MB)
