Indoor and outdoor temperature and humidity probe with 4-20mA output

Reference AR003830

  • Temperature and humidity.
  • Wall mounting.
  • Indoor use.
  • Calibration certificate.
2.25MB Download

Quick Start | Indoor and outdoor probe for temperature and humidity with 4-20mA output

2.77MB Download

Introduction Manual | Indoor and outdoor probe for temperature and humidity with 4-20mA output

Product features Indoor and outdoor temperature and humidity probe with 4-20mA output

TECHNICAL DATA

Transmitter ambient temperature and relative humidity, wall mounting, indoor use.

Measured values ​​can be calculated in dew point, absolute humidity, specific humidity, ratio of mixtures, specific enthalpy.

INCLUDED IN DELIVERY

  • T3110
  • Manual
  • Traceable calibration certificate
  • Free Tsensor configuration software

MEASURED VALUES

- Temperature
- Relative humidity
- Calculated values ​​(dew point, etc.)

Relative humidity range: 0 to 100%

Relative humidity measurement uncertainty: ± 2.5% RH from 5 to 95% at 23 ° C

Temperature measurement uncertainty: ± 0.4 ° C

Available temperature units: degrees Celsius, Fahrenheit

Uncertainty and dew point measurement range: ± 1.5 ° C at ambient temperature T <25 ° C and RH> 30%
Range -60 to +80 ° C

Uncertainty and range Absolute humidity: ± 1.5g / m3 at ambient temperature T <25 ° C
Range 0 to 400 g / m3

Uncertainty and specific humidity range: ± 2g / kg at ambient temperature T <35 ° C
range 0 to 550 g / kg

Uncertainty and ratio range of mixtures: ± 2g / kg at ambient temperature T <35 ° C
Range 0 to 995 g / kg

Uncertainty and specific enthalpy range: ± 3kJ / kg at ambient temperature T <25 ° C
Range: 0 to 995 kJ / kg

Temperature measuring range: -30 to +80 ° C

Device operating temperature: Reading up to 70 ° C beyond turn off the display

Humidity temperature compensation: The whole beach

Current output - 2 wires: 4-20mA, galvanic isolation

Configuration of outputs and ranges: by user via software and cable (option)

Protection filter: 0.025mm - Filter with stainless steel mesh

Protection sign : IP65 electronic IP40 sensor

Supply : 9-30VDC

Dimensions: 88.5 x 170 x 39.5 mm (W x H x D), Probe length 75 mm

Weight: About 150g

Warranty: 3 years
