Web sensor - Remote hygrometer and thermometer with Ethernet interface - POE

Reference: AR003832

Web sensor - Remote hygrometer and thermometer with Ethernet interface - POE
  • Temperature and humidity.
  • Remote alarm.
  • Capacitive polymer sensor.
  • Dual display.

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "Web sensor - Remote hygrometer and thermometer with Ethernet interface - POE"

TECHNICAL DATA

T-line web sensor at room temperature and relative humidity with Power over Ethernet functionality.

Alarm remote.

PoE Web Sensor with integrated sensors relative humidity and temperature.

Le high precision capacitive polymer sensor provides excellent long-term calibration stability and ultimate accuracy.

Le dual liquid crystal display is an advantage.

Functionality power over Ethernet IEEE 802.3af compliant is supported.

The measured values ​​are also converted to another interpretation of humidity: dew point temperature, absolute humidity, specific humidity, mixing rate and specific enthalpy.

INCLUDED IN DELIVERY

  • T3610
  • Manual
  • Traceable calibration certificate
  • Free Tsensor configuration software
  • COMET Cloud for 3 months


MEASURED VALUES

- Temperature
- Relative humidity
- Calculated values ​​(dew point, etc.)

Relative humidity range of: 0 to 100%

Accuracy of the relative humidity measurement: ± 2,5% relative humidity from 5 to 95% at 23 ° C

Accuracy of temperature output: ± 0,6 ° C

Resolution: 0.1 ° C, 0.1% RH

Measuring interval: 2s

Available temperature units: degrees Celsius, degrees Fahrenheit

Calculated values: dew point, absolute humidity, specific humidity, mixing ratio, specific enthalpy

Dew point temperature output accuracy and range - for details see graphics in manual: ± 1,5 ° C at ambient temperature below 25 ° C and RH> 30%
range -60 to + 80 ° C

Temperature compensation of the humidity sensor on: all temperature ranges

Operating temperature range: -20 to + 60 ° C

IP protection: electronic IP30

LAN connection: RJ-45, 10Base-T or 100Base-TX connector

Communication protocols: WWW, Modbus TCP, SNMPv1, SOAP, XML

Alarm protocols: Email, SNMP Trap, Syslog

Configuration: T-Sensor, WWW configuration

Supply : power supply via Ethernet according to IEEE 802.3af or 5Vdc

Power connector: coaxial, diameter 5,5 x 2,1 mm

Dimensions: 136 x 201 x 45 mm (W x H x D), rod length 75 mm

Weight: about 360g

Warranty: 3 years

General

  • Reference AR003832
  • Name Web sensor - Remote hygrometer and thermometer with Ethernet interface - POE

Features

  • Measured Humidity
  • Product Type Head / terminal probes
  • Communication ETHERNET - TCP / IP

Attachments

Web sensor - Remote hygrometer and thermometer with Ethernet interface - POE - Cloud Security
Download (1.52MB)
Web Sensor - Remote Hygrometer and Thermometer with Ethernet Interface - POE - Cloud Support
Download (1.2MB)
Web Sensor - Remote Hygrometer and Thermometer with Ethernet Interface - POE - Introduction Manual
AR004585 / AR004633 / AR003832 / AR006623 / AR006624 / AR006625 / AR006626 / AR006627 / AR004933 / AR006628 / AR004794 / AR006629 / AR006630 / AR006631 / AR006632
Download (3.67MB)
Web sensor - Remote hygrometer and thermometer with Ethernet interface - POE - Quick Start
AR004585 / AR004633 / AR003832 / AR006623 / AR006624 / AR006625 / AR004794 / AR006629 / AR006630 / AR006631 / AR006632
Download (999.07KB)
