Web sensor - Hygrometer - Thermometer with Ethernet interface

Reference: AR006623

405,13 €
Quantity Unit price You save
10 364,62 € Up to €405,12
25 346,39 € Up to €1
50 328,16 € Up to €3

Customization

Don't forget to save your personalization to be able to add it to the basket

250 characters max
Web sensor - Hygrometer - Thermometer with Ethernet interface
  • Temperature, relative humidity.
  • Capacitive polymer sensor.
  • Power over Ethernet.
  • Long-term calibration stability.
Delivery in 3 to 5 weeks

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "Web Sensor - Hygrometer - Thermometer with Ethernet interface"

TECHNICAL DATA

T-line web sensor at ambient temperature and relative humidity with Power over Ethernet functionality.

Alarm remote.

PoE Web Sensor with relative humidity and temperature probe on the cable.

Le high precision capacitive polymer sensor provides excellent long-term calibration stability and ultimate accuracy.

Le dual liquid crystal display is an advantage.

La power over Ethernet functionality IEEE 802.3af compliant is supported.

The measured values ​​are also converted to another interpretation of humidity: dew point temperature, absolute humidity, specific humidity, mixing rate and specific enthalpy.

The device is supplied with a T + RH probe with a 1 meter cable.

INCLUDED IN DELIVERY

  • T3611
  • Manual
  • Traceable calibration certificate
  • Free Tsensor configuration software
  • Cloud for 3 months


MEASURED VALUES

- Temperature
- Relative humidity
- Calculated values ​​(dew point, etc.)

Relative humidity range: 0 to 100%

Accuracy of the relative humidity measurement: ± 2,5% relative humidity from 5 to 95% at 23 ° C

Accuracy of temperature output: ± 0.4 ° C

Resolution: 0.1 ° C, 0.1% RH

Measuring interval: 2s

Available temperature units: degrees Celsius, degrees Fahrenheit

Calculated values: dew point, absolute humidity, specific humidity, mixing ratio, specific enthalpy

Dew point output accuracy and range - for details see graphics in manual: ± 1,5 ° C at ambient temperature below 25 ° C and relative humidity> 30%
range -60 to + 80 ° C

Temperature compensation of humidity sensor: the entire temperature range

Temperature operating range: -20 to +60 ° C

IP protection: Electronics IP30, sensors IP40

LAN connection: RJ-45, 10Base-T or 100Base-TX connector

Communication protocols: WWW, Modbus TCP, SNMPv1, SOAP, XML

Alarm protocols: Email, SNMP Trap, Syslog

Configuration: T-Sensor, WWW configuration

Filtering capacity of the sensor cover: 0.025mm - filter with stainless steel mesh

Supply : Power over Ethernet according to IEEE 802.3af or 5Vdc

Power cable : coaxial, diameter 5,5 x 2,1 mm

Probe cable length: 1m, 2m or 4m optional

Dimensions: 136 x 159 x 45mm (W x H x D), probe length 88mm, probe diameter 18mm

Weight: About 380g

Warranty: 3 years

General

  • Reference AR006623
  • Name Web sensor - Hygrometer - Thermometer with Ethernet interface

Features

  • Measured Humidity
  • Product Type Head / terminal probes
  • Communication ETHERNET - TCP / IP

Attachments

Web sensor - Hygrometer - Thermometer with Ethernet interface - Cloud Security
Download (1.52MB)
Web Sensor - Hygrometer - Thermometer with Ethernet Interface - Cloud Support
Download (1.2MB)
Web Sensor - Hygrometer - Thermometer with Ethernet Interface - Introduction Manual
AR004585 / AR004633 / AR003832 / AR006623 / AR006624 / AR006625 / AR006626 / AR006627 / AR004933 / AR006628 / AR004794 / AR006629 / AR006630 / AR006631 / AR006632
Download (3.67MB)
Web sensor - Hygrometer - Thermometer with Ethernet interface - Quick Start
AR004585 / AR004633 / AR003832 / AR006623 / AR006624 / AR006625 / AR004794 / AR006629 / AR006630 / AR006631 / AR006632
Download (999.07KB)
