The wireless high temperature sensor uses a resistance thermometer to accurately measure temperatures from -50 ° C to + 370 ° C. Perfect for critical high temperature applications such as ovens, heaters and boilers. User customization allows you to set the frequency of sensor readings and create notifications from the system when certain criteria are met or exceeded.
The high temperature sensor is not designed for humid and very humid environments. This sensor should only be used in dry and low humidity environments. If you need a temperature sensor that operates at extreme temperatures and can resist humidity or condensation, please consult our thermocouple sensors.
Main “Internet of Things” solutions for companies
The sensors offer a range of standard sensors with a range of up to over 350m through walls (12 to 14 walls generally). The use of Frequency Spread Spectrum (FHSS) also allows the sensors to have better immunity to interference from other wireless devices.
Superior power management provides the sensors with almost twice the battery life of standard wireless sensors.
- Button cell sensors typically last more than 3 years.
- AA and industrial sensors generally last up to 12 years.
The products use the new Encrypt-RF® Security system (256-bit Diffie Hellman key exchange and AES-128 CBC encryption for all sensor data messages). Security is therefore maintained at all communication points, gateway sensor, software gateway.
The built-in data storage allows the sensors to store data messages if communication with a wireless gateway is interrupted (power outage, Internet connection outage or out of range). Messages that cannot be delivered will be time stamped and stored in memory (up to the last 512 messages) until communication with the gateway is restored, in which case all messages will be transmitted.
Over-the-air updates allow products to be updated remotely if new patches or new features are available.
The standard version of this sensor is powered by two replaceable 1,5V AA size batteries (included with purchase). This sensor is also available with an AC power option. The in-line version of this sensor is equipped with a cylindrical power connector allowing it to be powered by a standard power supply of 3 to 3,8 V. The mains powered version also uses two standard 1,5 V AA batteries as backup for uninterrupted operation in the event of a power failure.
Power options must be selected at the time of purchase, as the internal sensor hardware must be modified to support the power requirements.
- Accurate to +/- 0,3 ° C at 0 ° C.
- RTD temperature range: -50 ° C to + 370 ° C. (-58 ° F to 700 ° F)
- Good for high temperature applications.
* The actual range may vary depending on the environment.
** Battery life is determined by the frequency of sensor reporting and other variables.
What does the data from this wireless sensor look like in the software?
* also available in ° C
What's in the box?
- Wireless sensor
- The mounting material
- 2 AA batteries
Resistance thermometer specifications
|RTD accuracy at 0 ° C
||+/- 0.3 ° C
|Time constant at 25 ° C
||15 sec max
||85g (3,7 oz w / 3 'probe)
|Probe operating temperature range
||-50 ° C to + 370 ° C
||2 replaceable 1,5 V AA batteries
||2,0 - 3,8 V (2 AA 1.5V batteries or optional power supply)
||At an hour-long heart rate, the included AA batteries typically last between 6 and 8 years. **
|Max operating temperature using AA alkaline
||-18 ° C to 55 ° C (0 ° F to 130 ° F)
|Max operating temperature using AA lithium
||-40 ° C to 60 ° C (-40 ° F to 140 ° F)
|Optimal battery operating temperature
||+ 10 ° C to + 50 ° C (+ 50 ° F to + 122 ° F)
868 MHz specifications
|Frequency of operation
||Operating frequency 868 MHz
||CE certified. Tested and found to comply: EN 300 220-2 V3.1.1 (2017-02), EN 300 220-2 V3.1.1 (2017-02) and EN 60950.
||Encrypt-RF® (Diffie-Hellman + AES-128 CBC key exchange)
|Range of devices
||Device range Wireless range up to 350m (12 to 14 walls)
Suggested applications for this sensor
- Boiler temperature monitoring to detect boiler failures
- Heating temperature monitoring
- Monitoring ovens and cooking appliances
- Intelligent machines and intelligent structures
- HVAC system monitoring to detect breakdowns or heating / cooling problems
