Universal, dual input, high performance HART temperature transmitter

Reference: GSEM310-XR

174,50 €

Customization

Don't forget to save your personalization to be able to add it to the basket

250 characters max
Universal, dual input, high performance HART temperature transmitter
  • HART 5,6,7 compatible.

  • Dual RTD, thermocouple, potentiometer and mV inputs.

  • Tested on isolated 4 kV DC input / output.

  • Versions for hazardous areas.

  • SIL approval.
Delivery in 3 to 5 weeks

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "Universal, Dual Input, High Performance HART Temperature Transmitter"

TECHNICAL DATA

The SEM310 HART Temperature Transmitter (Generic Device) is a universal device that accepts the most commonly used Pt100, thermocouple, mV, potentiometer sensors and generates a standard mA transmit signal (4 to 20). Compatible with HART 5, 6 or 7, the product can be easily programmed using our free USB Speedlink software and a standard USB cable (safe zone version). It can also be programmed via a HART communication device / system.
Isolation is a standard feature to overcome the potential effects of the ground loop and a sensor homing feature allows the transmitter to be calibrated to a particular sensor.
This HART temperature transmitter has two inputs. This allows the connection of two sensors. Math functions such as difference, average, highest, lowest, sensor redundancy (TC and mV only) are available.
The mathematical function of the two inputs is then reflected in the 4 to 20 mA output.
The product also comes with a calibration feature so that the offset and range can be adjusted to match a particular temperature sensor when applied at a known reference temperature.
The HART temperature transmitter can be ordered with any of our temperature sensors and connection heads. We can supply ExD and Exia approved safety probe sets or temperature probe sets with the temperature transmitter included.
If you already know the specifications you need, we can configure the product for you at no additional cost.

General

  • Reference GSEM310-XR
  • Name Universal, dual input, high performance HART temperature transmitter

Features

  • Type Connection head
  • Type of entries PT100
    PT1000
    Potentiometer
    Thermocouple
    mV
  • Type of outputs 4.20mA
