Wired CO2 sensor with Ethernet interface

Reference AR004793

  • CO2 sensor.
  • High resistance to pollution.
  • Maintenance free, long term stability.
  • Easy wireless communication.
1.52MB Download

Cloud Security | Wired CO2 sensor with Ethernet interface

1.2MB Download

CloudSupport | Wired CO2 sensor with Ethernet interface

2.41MB Download

Introduction Manual | Wired CO2 sensor with Ethernet interface

1.21MB Download

Quick Start | Wired CO2 sensor with Ethernet interface

Product features Wired CO2 sensor with Ethernet interface

TECHNICAL DATA

T-line web sensor carbon dioxide.

Alarm remote.

Web sensor with CO2 probe with 1 meter cable.

Cable length 2m or 4m optional.

A temperature and CO2 adjustment procedure at several points allows excellent CO2 measurement accuracy over the entire temperature operating range; It is a must for process control and outdoor applications.

The procedure of dual wavelength NDIR CO2 detection automatically compensates for the effects of aging.

The CO2 module is highly resistant to pollution and offers maintenance-free operation and exceptional long-term stability.

INCLUDED IN DELIVERY

  • T5541
  • Manual
  • Traceable calibration certificate
  • Free Tsensor configuration software
  • Cloud for 3 months


MEASURED VALUES

- CO2

CO 2 concentration measurement range: 0 to 10000ppm

Accuracy of CO2 concentration measurement: ± (100ppm + 5% from reading) at 25 ° C and 1013hPa

Resolution: 1ppm

Measuring interval: 15s

Temperature operating range: -30 to +60 ° C

Protection: IP30

LAN connection: RJ-45, 10Base-T or 100Base-TX connector

Communication protocols: WWW, ModbusTCP, SNMPv1, SOAP, XML

Alarm protocols: Email, SNMP Trap, Syslog

Configuration: T-Sensor, WWW setup

Power : 9 to 30Vdc, maximum consumption 1W

Power cable : coaxial, diameter 5,5 x 2,1 mm

Probe cable length: 1m, 2m or 4m optional

Dimensions: 88,5 x 72,5 x 39,5 mm (W x H x D)

Weight: about 240g - 1m probe

Warranty: 3 years
