Indoor temperature, humidity, bar. pressure transmitter - RS232 output
Reference AR004921
Product features Indoor temperature, humidity, bar. pressure transmitter - RS232 output
TECHNICAL DATA
Transmitter ambient temperature, humidity and atmospheric pressure.
Use in shooting.
For demanding interiors in building energy management and HVAC systems.
Are designed for Easy installation on the housings of wiring KU68 ordinary for household switches and sockets.
INCLUDED IN DELIVERY
- T7318
- Manual
- Traceable calibration certificate
- Free Tsensor configuration software
MEASURED VALUES
- Temperature
- Relative humidity
- Calculated values (dew point, etc.)
- Atmospheric pressure
Relative humidity range: 5 to 95% RH
Accuracy of the relative humidity measurement: ± 2,5% relative humidity from 5 to 95% at 23 ° C
Accuracy of temperature output: ± 0.5 ° C
Available temperature units: degrees Celsius, Fahrenheit
Dew point output accuracy and range - for details see graphs: ± 1,6 ° C at ambient temperature T <25 ° C and relative humidity> 30%
range -60 to +80 ° C
Accuracy and absolute humidity output range: ± 1,5 g / m3 at ambient temperature T <25 ° C
range from 0 to 400 g / m3
Accuracy and specific humidity output range: ± 2 g / kg at room temperature T <35 ° C
range 0 to 550 g / kg
Accuracy and output range of mixing ratio: ± 2,2 g / kg at room temperature T <35 ° C
range from 0 to 995 g / kg
Precision and range of specific enthalpies: ± 3,5 kJ / kg at ambient temperature T <25 ° C range: 0 to 995 kJ / kg
Maximum measuring range: 600 to 1100hPa
Precision of pressure measurement: ± (1,3hPa + 0,06% of the adjusted output range) at 23 ° C from 800 to 1100 hPa
Available pressure units: hPa, kPa, mbar, mmHg, inHg, inH2O, PSI, oz/in2
Communication protocol : ModBus RTU and Advantech ADAM compatible protocol
Communication speed: 110 to 115200 Bd
Protection: IP20
Supply : 9-30Vdc, current consumption about 6mA
Dimensions: 88 x 106 x 33 mm (W x H x D)
Material : ABS
Color: White
Weight: about 150g
Warranty: 3 years
