Discreet temperature sensors

Reference: GTT-518R

Discreet temperature sensors
  • Available in plastic, brass, stainless steel or aluminum
  • If no finish is specified, the standard off-white plastic thermowell will be provided.

International shipping

Standard or express delivery

Secure Payments

All payments are secure and approved.

Best price guarantee

Contact us to define your payment method.

+33-233-611-670

English - French - German - Spanish

Product details about "Discrete Temperature Sensors"

The thermowell temperature sensor measures the air temperature inside buildings. It contains either a high quality thermistor or a nickel or platinum sensing element. The sensitive element is mounted in an elegant thermowell for surface mounting (usually on a mounting plate or ceiling tile). The standard GTT-518R sensor thermowell is made of off-white plastic.

Possible options:

  • Discrete temperature sensor, passive output 10K3A1, Trend, Seachange, Cylon, Distech, with aluminum cap

  • Discrete temperature sensor, passive output 10K4A1, Andover

  • Discrete temperature sensor, passive output 20K6A1, Honeywell

  • Discrete temperature sensor, with selectable active output 0-10 VDC / 4-20 mA, temperature output ranges -10 to + 40 ° C or -10 to + 110 ° C (switchable)

  • Discrete temperature sensor, with selectable active output 0-10 VDC / 4-20 mA, customized temperature output in the range of -10 to + 60 ° C

  • Discrete temperature sensor, passive output PT100A, Serck

  • Discrete temperature sensor, passive output PT1000A, Cylon

  • Discrete temperature sensor, passive output Ni1000A, Sauter

  • Discrete temperature sensor, passive output Ni1000A / TCR (LAN1), Siemens

  • Discrete temperature sensor, passive output SAT1, Satchwell

  • Discrete temperature sensor, passive output STA1, Landis & Staefa

  • Discrete temperature sensor, passive output TAC1, TAC

  • Discrete temperature sensor, passive output 2.2K3A1, Johnson Controls

  • Discrete temperature sensor, passive output 3K3A1, Alerton

  • Discrete temperature sensor, passive output 30K6A1, Drayton

  • Discrete temperature sensor, passive output 50K6A1, Ambiflex

  • Discrete temperature sensor, passive output SAT2, Satchwell

  • Discrete temperature sensor, passive output SAT3, Satchwell

  • Discrete temperature sensor, passive output SIE1, Siebe

  • Discrete temperature sensor, passive output STA2, Landis & Staefa

  • Discrete temperature sensor, passive output 10K NTC, Carel

For more information, do not hesitate to consult the product data sheet which you will find in the "attached documents" tab.

General

  • Reference GTT-518R
  • Name Discreet temperature sensors

Features

  • Product Type NTC
    Ni1000
    Ni10000
    Pt100
    Pt500
    Pt1000
  • Protection sign IP30
  • Maximum operating temperature 60°C
  • Model Interior
    Wired probe
  • Cable length 2000 mm
